NNVT NVT7 FOM1800+ GT7864 P45 MX10160 2343076 FOM:1997,44

Specifications：

PN:GT7864

SN:2343076

FOM:1997,44

Cathode Sensitivity 2856K:1350µA/lm

Max brightness：6.76

Gain：12400 cd·m⁻²·lx⁻¹

Resolution

Center：64

Peripheral：64

EBI:0.15

SNR:31.21

MTTF:10000h

NVT-7 features a broad spectral response and high near-infrared (NIR) sensitivity. It incorporates a diffraction grating ，S25R photocathode technology. Compared with standard Gen2+ image intensifier tubes, it delivers cathode sensitivity exceeding 1000 µA/lm, spectral extension beyond 1000 nm, and the ability to image 1064 nm laser radiation. The halo is reduced to below 0.7 mm, and Autogated power supply is included for bright-source protection.
